for iPod Classic Toshiba 1.8 160GB MK1626GCB CE-ATA/ZIF Hard Dri
[MK1626GCB_36]

Sale Price: £35.89
Availability: In Stock
Quantity:

the HDD only for ipod classic, can't run in any laptop

4ca4_3.jpg   picture by ventures_cn1

The MK1626GCB reinforces Toshiba’s technical and manufacturing expertise by offering 160GB on only 2 platters. Featuring the CE-ATA interface, which is optimised for consumer electronics products, Toshiba’s new 160GB HDD builds upon growing market demand for high capacity, lightweight next generation mobile media devices like Mp3 players and personal media players. Alongside the increase in capacity, the 160GB HDD operates at only 3.600 rpm. Due to this speed rate the drive offers extreme high energy efficiency and extraordinary battery life compared with conventional HDDs, which is very important for consumer electronic devices.

    4e41_3.jpg picture by ventures_cn1 4f62_3.jpg picture by   ventures_cn1

With the MK1626GCB, Toshiba Storage Device Division is offering consumer electronics designers the perfect medium to develop high performance products that offer the optimum combination of low power consumption and substantial storage in a highly portable form factor
160 GB capacity
CE-ATA interface
3,600 rpm
High energy efficiency
2 platters, 8mm of height
Features
Part number HDD1B01
Formatted capacity 160,042 MByte
Form factor 1.8 inch
Interface type CE-ATA (LIF)

Supported interface standards CE-ATA x8
CE-ATA 1.1

Head/actuator technology "Ramp-Load" Technology
PMR (Write)/TMR (Read)

Shock detection Shock sensor circuit
S.M.A.R.T. The SMART command set is supported.

--------------------------------------------------------------------------------
Physical parameters
Number of platters 2
Number of cylinders 83,988
Number of heads 4

--------------------------------------------------------------------------------
Bytes/sector
Bytes/sector Host: 512
Disk: 4,096

--------------------------------------------------------------------------------
Access times
Average seek time 15 ms
Maximum seek time 26 ms
Track-to-track seek time 3 ms

--------------------------------------------------------------------------------
Transfer rates
Internal From 171 MBit/s to 377 MBit/s
Host 52 MByte/s

--------------------------------------------------------------------------------
Rotational speed
Rotational speed 3,600 RPM

--------------------------------------------------------------------------------
Buffer
Buffer size 160 kByte
Cache Read-ahead cache
Write cache


--------------------------------------------------------------------------------
Reaction times
Start time, typical (up to Drive Ready) 0.3 s
Start time, maximum (up to Drive Ready) 0.4 s
Recovery time (from stand-by, typical) 3 s
Recovery time (from stand-by, maximum) 20 s

--------------------------------------------------------------------------------
Reliability specifications
MTBF 300,000 Hours
Power-on hours <333 hours/month Hours
Product life 5 years or 20,000 POH (whatever comes earlier)
Seek error rate 1 error per 10^6 seeks
Non-recoverable error rate 1 error per 10^13 seeks
Preventive maintenance No preventive maintenance is required

--------------------------------------------------------------------------------
Power consumption
Start (Maximum) 1.8 W
Seek (Average) 0.9 W
Read (Average) 0.8 W
Write (Average) 0.8 W
Low-power idle (Average) 0.3 W
Stand-by (Average) 0.1

--------------------------------------------------------------------------------
Power supply motor
Supply voltage +3.3 V (+/-5 %)

Allowable noise/ripple Max. 70 mV

--------------------------------------------------------------------------------
Power supply logic
Supply voltage +3.3 V (+/-5 %)

Allowable noise/ripple Max. 70 mV

--------------------------------------------------------------------------------
Mechanical specifications
Drive width 54 mm
Drive height 8.0 mm
Drive depth 71 mm
Drive weight 0.059 kg
Drive orientation The drive can be installed in all axes (6 directions)

--------------------------------------------------------------------------------
Temperature
Operating From 5 °C to 60 °C
Non-operating From -20 °C to 65 °C
Shipping From -40 °C to 70 °C

--------------------------------------------------------------------------------
Humidity
Operating From 8 % to 90 %
Non-operating From 8 % to 90 %
Shipping From 5 % to 90 %

--------------------------------------------------------------------------------
Wet bulb
Operating (Maximum) 29 °C
Non-operating (Maximum) 40 °C

--------------------------------------------------------------------------------
Vibration
Operating (Maximum) 2 G, with 15 - 500 Hz
Non-operating (Maximum) 5 G, with 15 - 500 Hz

--------------------------------------------------------------------------------
Shock
Operating (Maximum) 500 G, with 2 ms half sine wave
Non-operating (Maximum) 1500 G, with 1 ms half sine wave
Shipping (Maximum) 0.7 m free drop with no unrecoverable error. Drive must be packed in Toshiba´s original shipping package. Apply shock in each direction of the drive´s three mutual perpendicular axis, one axis at a time.

--------------------------------------------------------------------------------
Altitude
Operating From -300 m to 3,000 m
Non-operating From -300 m to 12,000 m

--------------------------------------------------------------------------------
Acoustic noise
Idle mode (Disk spinning) Max. 16 dB
Random seek Max. 22 dB

--------------------------------------------------------------------------------
BIOS specifications
Number of cylinders (Logical) 16,383
Number of heads (Logical) 16
Number of sectors/track (Logical)
